Horizontal type low pressure injection machine for Mobile Phone Battery Producing Machine
1>Machines which Inject Glue to Protect the Batteries.
2> Used for battery factories automatical production in mobile cell phone batteries, etc.
3> Do 600-700pcs injection per hour.
4> Touch screen operation, easy and fast responding.
5> 0-1 worker to operate the machine, fast and with great efficiency.
Can be connected to other machines to proceed automatically.
6> Overseas sales office in New Delhi, India.
7> 12 months warranty and life-time maintenance.
Technical Parameters:
plastic injection blow moulding machine
| Plastic machinery | 350 |
| Size(mm)Machine(kg) | 850×1015×1640(270kg) |
| WorkStation Height(mm) | 840 |
| Plant View(mm) | 1020×850 |
| Packing(mm)Size(kg) | 950×1120×1700(315kg) |
| Melting Tank | (3Liter)×1 |
| Gun & Tip Angle | (36.4°60°.90°)optional |
| Heated Hose | N/A |
| Electricity | 200-240VAC/1Phase/50 or 60Hz |
| Temperature Control Zones | 2 |
| Temperature Range | 70℃- 260℃ |
| Max.Power(Kw) | 4 |
| Working pressure(Mpa) | 0.5(Mpa)~0.8(Mpa) |
| Air Consumption | 0.1m3/min |
| Clamping Device | (Pneumatic) |
| Clamping Force | Max.1.2Ton |
| Clamping Stroke(mm) | 125mm or 150mm optional |
| Control System | Text display |
| Standard Mold Set Size(mm) | 180×100×150(16kg) |
| Max.Mold Set Size(mm) | 300×120×150 |
| Max. Part Size(mm) | 50×45×8 |
Machine display
Scop of application
Shipping
Our Service
Pre-sales
1) Inquiry and consulting support. All will be replied in 12 hours.
2) View our Factory and testing the machine, demonstrate how the machine work.
After-Sales
1) Training how to install the machine, training how to use the machine.
2) Engineers available to service machinery overseas
3) 1-year guarantee ( free maintain in a year)
4) Replacement parts and other accessories provided
